UTD-IPH00-01024-M100-5TW Encoder
7500.0 INR/Number
Product Details:
- Sensor Type Programmable Incremental
- Product Type UTD-IPH00-01024-M100-5TW
- IP Rating IP65
- Cable Length 5 Meter (m)
- Connectivity Type Axial/Radial
- Speed Range >100RPM
- Weight 880 Grams (g)
- Click to View more
X
UTD-IPH00-01024-M100-5TW Encoder Price And Quantity
- 1 Number
- 3000.00 - 3000.00 INR/Number
- 7500.0 INR/Number
UTD-IPH00-01024-M100-5TW Encoder Product Specifications
- >100RPM
- Steel
- Axial/Radial
- IP65
- 5 Meter (m)
- 880 Grams (g)
- Programmable Incremental
- UTD-IPH00-01024-M100-5TW
UTD-IPH00-01024-M100-5TW Encoder Trade Information
- Cash in Advance (CID)
- All India
Product Description
| Housing Material | Steel |
| Housing Coating | Zinc Plated |
| Flange Type | Clamp, 58 mm (M) |
| Flange Material | Aluminum |
| Shaft Type | Solid, Single Flat, Length = 20 mm |
| Shaft Diameter | 10 mm (0.39") |
| Shaft Material | Stainless Steel V2A (1.4305, 303) |
| Max. Shaft Load | Axial 40 N, Radial 110 N |
| Rotor Inertia | ï 30 gcmï [ï 0.17 oz-inï] |
| Friction Torque | ï 3 Ncm @ 20 C (4.2 oz-in @ 68 F) |
| Max. Permissible Mechanical Speed | ï 12000 1/min |
| Shock Resistance | ï 100 g (half sine 6 ms, EN 60068-2-27) |
| Permanent Shock Resistance | ï 10 g (half sine 16 ms, EN 60068-2-29) |
| Vibration Resistance | ï 10 g (10 Hz ï 1000 Hz, EN 60068-2-6) |
| Length | 92 mm (3.62") |
| Weight | 880 g (1.94 lb) |
| Minimum Mechanical Lifetime (108 revolutions with Fa/Fr) |
430 (20 N / 40 N), 150 (40 N / 60 N), 100 (40 N / 80 N), 55 (40 N / 110 N) |
