Posital Fraba UTD-IPH00-XXXXX-04M0-2TW
7000.0 INR/Number
Product Details:
- Weight 480 Grams (g)
- IP Rating IP65
- Cable Length 2 Meter (m)
- Product Type Programmable Incremental Encoder
- Material Steel
- Click to View more
X
Posital Fraba UTD-IPH00-XXXXX-04M0-2TW Price And Quantity
- 7000.0 INR/Number
- 1 Number
- 8000.00 - 9000.00 INR/Number
Posital Fraba UTD-IPH00-XXXXX-04M0-2TW Product Specifications
- Programmable Incremental Encoder
- Steel
- 2 Meter (m)
- IP65
- 480 Grams (g)
Posital Fraba UTD-IPH00-XXXXX-04M0-2TW Trade Information
- Cash in Advance (CID)
- All India
Product Description
| Outputs | |
| Output Driver | Push-Pull (HTL) |
| Output Voltage High Level Push-Pull (HTL) | > 4 V @ 4.75-9 V Supply Voltage > V-3 V @ 9-30 V Supply Voltage |
| Output Voltage Low Level Push-Pull (HTL) | < 0.5 V |
| Output Voltage High Level RS422 (TTL) | > 4 V |
| Output Voltage Low Level RS422 (TTL) | < 0.5 V |
| Maximum Frequency Response | 1 MHz |
| Maximum Switching Current | 50 mA per Channel |
| Electrical Data | |
| Supply Voltage | 4.75 ï 30 VDC |
| Current Consumption | ï140mA @ 5V DC, ï70mA @ 10V DC, ï40mA @ 24V DC |
| Power Consumption | ï 1.0 W |
| Start-Up Time | < 1 s |
| Min. Load Resistance | 120 ï |
| Reverse Polarity Protection | Yes |
| Short Circuit Protection | Yes |
| EMC: Emitted Interference | DIN EN 61000-6-4 |
| EMC: Noise Immunity | DIN EN 61000-6-2 |
| MTTF | 280 years @ 40 C |
| Sensor | |
| Technology | Magnetic |
| Accuracy (INL) | ï0.0878 (ï 12 bit) |
| Duty Cycle | 180 ï 27 (Speed > 100RPM) |
| Phase Angle | 90 ï 14 (Speed > 100RPM) |
| Environmental Specifications | |
| Protection Class (Shaft) | IP65 |
| Protection Class (Housing) | IP65 |
| Operating Temperature | -30 C fixed (-22 F), -5 C flexible (+23 F) - +80 C (+176 F) |
| Humidity | 98% RH, no condensation |
