Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW
9000 INR/Number
Product Details:
- Connectivity Type Cable / Connector
- Product Type UTD-IPH00-XXXXX-AAB0-2TW
- IP Rating IP65
- Features Push-Pull (HTL)
- Sensor Type Incremental Encoder
- Material Stainless steel
- Click to View more
X
Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW Price And Quantity
- 9000 INR/Number
- 1 Number
- 8000.00 - 9000.00 INR/Number
Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW Product Specifications
- UTD-IPH00-XXXXX-AAB0-2TW
- Cable / Connector
- Stainless steel
- IP65
- Push-Pull (HTL)
- Incremental Encoder
Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW Trade Information
- Cash in Advance (CID)
- All India
Product Description
| Interface | |
| Interface | Programmable Incremental |
| Programming Functions | PPR (1-16384), Output, Counting Direction |
| Configuration Tool | UBIFAST Configuration Tool (Version 1.6.3) |
| Outputs | |
| Output Driver | Push-Pull (HTL) |
| Output Voltage High Level Push-Pull (HTL) | > 4 V @ 4.75-9 V Supply Voltage > V-3 V @ 9-30 V Supply Voltage |
| Output Voltage Low Level Push-Pull (HTL) | < 0.5 V |
| Output Voltage High Level RS422 (TTL) | > 4 V |
| Output Voltage Low Level RS422 (TTL) | < 0.5 V |
| Maximum Frequency Response | 1 MHz |
| Maximum Switching Current | 50 mA per Channel |
| Electrical Data | |
| Supply Voltage | 4.75 30 VDC |
| Current Consumption | 140mA @ 5V DC, 70mA @ 10V DC, 40mA @ 24V DC |
| Power Consumption | 1.0 W |
| Start-Up Time | < 1 s |
| Min. Load Resistance | 120 |
| Reverse Polarity Protection | Yes |
| Short Circuit Protection | Yes |
| EMC: Emitted Interference | DIN EN 61000-6-4 |
| EMC: Noise Immunity | DIN EN 61000-6-2 |
| MTTF | 280 years @ 40 C |
| Sensor | |
| Technology | Magnetic |
| Accuracy (INL) | 0.0878 ( 12 bit) |
| Duty Cycle | 180 27 (Speed > 100RPM) |
| Phase Angle | 90 14 (Speed > 100RPM) |
| Environmental Specifications | |
| Protection Class (Shaft) | IP65 |
| Protection Class (Housing) | IP65 |
| Operating Temperature | -30 C fixed (-22 F), -5 C flexible (+23 F) - +80 C (+176 F) |
| Humidity | 98% RH, no condensation |
FAQs of Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW:
Q: What is the resolution of the Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW?
A: The resolution of the Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW is 30mm.Q: What type of output does the Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW have?
A: The Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW has 2 x PNP-NO (OSSD safety output).Q: What is the application of the Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW?
A: The application of the Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW is Emitter + Receiver.Q: What is the measurement range of the Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW?
A: The measurement range of the Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW is 0.2 to 19m.Q: What is the mounting type of the Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW?
A: The mounting type of the Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW is Standard "L" Mounting Brackets with a 6 pcs kit.Q: What is the material used in making the Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW?
A: The Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW is made of Painted aluminum, PMMA, PC MAKROLON, and Stainless steel.Q: What is the IP rating of the Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW?
A: The Posital Fraba UTD-IPH00-XXXXX-AAB0-2TW has an IP rating of IP65.Tell us about your requirement
