EX-13A Ultra-slim Photoelectric Sensor

1800 INR/Number

Get a Price/Quote

Product Details:

Measurement Range 500 mm
Usage & Applications Ultra-slim Photoelectric Sensor EX-10 Ver.2
Features Ultra-slim Photoelectric Sensor EX-10 Ver.2
Cable Type Yes
Warranty 1 Year
Cable Length 2 Meter (m)
Sensor Type Ultra-slim Photoelectric Sensor
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

EX-13A Ultra-slim Photoelectric Sensor Price And Quantity

Minimum Order Quantity 1 Number
Price 1800 INR/Number

EX-13A Ultra-slim Photoelectric Sensor Product Specifications

IP Rating IP67 (IEC)
Sensor Type Ultra-slim Photoelectric Sensor
Material Enclosure: Polyarylate Lens: Polyarylate
Weight 50 Grams (g)
Output NPN open-collector transistor
Cable Length 2 Meter (m)
Voltage 12 to 24
Warranty 1 Year
Cable Type Yes
Function Thru-beam [Front sensing]
Measurement Range 500 mm
Usage & Applications Ultra-slim Photoelectric Sensor EX-10 Ver.2
Product Type EX-13A
Features Ultra-slim Photoelectric Sensor EX-10 Ver.2

EX-13A Ultra-slim Photoelectric Sensor Trade Information

Payment Terms Cash in Advance (CID)
Main Domestic Market All India

Product Description

Product Number	EX-13A
Part Number	EX-13A
Products Name	Ultra-slim Photoelectric Sensor
Product details	Thru-beam [Front sensing]
Output	NPNopen-collector transistor
Applicable regulations and certifications	CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations), ISO 13849-1 (Category 1, PLc) (Note), UL Recognition certification (Note) : Conformed from December 2021 production.
Sensing range	500 mm19.685 in
Min. sensing object	2 mm0.079 inopaque object
Hysteresis	-
Repeatability(perpendicular to sensing axis)	0.05 mm0.002 inor less
Supply voltage	12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less
Current consumption	Emitter: 10 mA or less Receiver: 10 mA or less
