RPL Automation Pvt. Ltd.
CX-412 Sensor
1400.0 INR/Number
Product Details:
- IP Rating IP67 (IEC)
- Cable Length 2 m
- Sensor Type Compact Photoelectric Sensor
- Application Thru-beam(Long sensing range)
- Measurement Range 15 m
- Product Type CX-412
- Material Enclosure: PBT (polybutylene terephthalate) Lens: acrylic Indicator cover: acrylic
- Click to View more
X
CX-412 Sensor Price And Quantity
- 1 Number
- 1400.0 INR/Number
CX-412 Sensor Product Specifications
- CX-412
- Thru-beam(Long sensing range)
- 1 year
- NPN open-collector transistor
- 100 Grams (g)
- 15 m
- IP67 (IEC)
- Enclosure: PBT (polybutylene terephthalate) Lens: acrylic Indicator cover: acrylic
- Compact Photoelectric Sensor
- 2 m
CX-412 Sensor Trade Information
- Cash in Advance (CID)
- All India
Product Description
| Product Number | CX-412 |
|---|---|
| Part Number | CX-412 |
| Products Name | Compact Photoelectric Sensor |
| Product details | Thru-beam(Long sensing range) |
| Response Time | 1 ms or less |
| Applicable regulations and certifications | CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations), UL Recognition Certification |
| Sensing range | 15 m 49.213 ft |
| Sensing object | 12 mm 0.472 in or more opaque object |
| Protection | IP67 (IEC) |
| Repeatability(perpendicular to sensing axis) | 0.5 mm 0.020 in or less |
| Supply voltage | 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less |
| Current consumption | Emitter: 20 mA or less Receiver: 10 mA or less |
| Output | NPN open-collector transistor |
