NA1-PK3 Picking Sensor
5000.0 INR/Number
Product Details:
- Cable Length 2 Meter (m)
- Features Compact Size Picking Sensor
- Sensor Type Picking Sensor
- Measurement Range 30-300 mm
- IP Rating IP 62 (IEC)
- Wireless No
- Cable Type Yes
- Click to View more
X
NA1-PK3 Picking Sensor Price And Quantity
- 5000.0 INR/Number
- 1 Number
NA1-PK3 Picking Sensor Product Specifications
- 2 Meter (m)
- Compact Size Picking Sensor
- Picking Sensor
- 30-300 mm
- IP 62 (IEC)
- 12 to 24 Volt (v)
- 50 Grams (g)
- No
- NPN
- 24.6 mm
- Yes
- 1 Year
- NA1-PK3
- Compact Size Picking Sensor NA1-PK3
- Enclosure: Heat-resistant ABS Lens cover: Acrylic Indicator cover: Acrylic
- Ultra-slim Body Picking Sensor
NA1-PK3 Picking Sensor Trade Information
- All India
Product Description
| Product Number | NA1-PK3 |
|---|---|
| Part Number | NA1-PK3 |
| Products Name | Compact Size Picking Sensor |
| Product details | NPN output |
| Protection | IP62 (IEC) |
| Sensing height | 49.2 mm |
| Sensing range | 30 to 300 mm (Note) The sensing range is the possible setting distance between the emitter and the receiver. |
| Beam pitch | 24.6 mm 0.969 in |
| Number of beam channels | 3 beam channels |
| Sensing object | 29 mm1.142 inor more opaque object (completely beam interrupted object) |
| Supply voltage | 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less |
| Current consumption | Emitter: 30 mA or less Receiver: 50 mA or less |
| Output | NPN open-collector transistor |
| Output :Utilization category | DC-12 or DC-13 |
