LX-101-Z Sensor
5000.0 INR/Number
Product Details:
- IP Rating IP67 (IEC)
- Application EMC Directive, RoHS Directive
- Measurement Range 10 3 mm
- Sensor Type Digital Mark Sensor
- Product Type Digital Mark Sensor
- Material Enclosure: PBT
- Input NPN
- Click to View more
X
LX-101-Z Sensor Price And Quantity
- 1 Number
- 1000.00 - 1000.00 INR/Number
- 5000.0 INR/Number
LX-101-Z Sensor Product Specifications
- NPN
- Digital Mark Sensor
- NPN
- Digital Mark Sensor
- 10 3 mm
- Enclosure: PBT
- IP67 (IEC)
- EMC Directive, RoHS Directive
LX-101-Z Sensor Trade Information
- Cash in Advance (CID)
- All India
Product Description
| Part Number | LX-101-Z |
| Regulatory compliance | EMC Directive, RoHS Directive |
| Sensing range | 10 ± 3 mm 0.394 ± 0.118 in |
| Spot size | 1 x 5 mm 0.039 x 0.197 in (at 10 mm 0.394 in setting distance) |
| Supply voltage | 12 to 24 V DC ± 10 % Ripple P-P 10 % or less |
| Current consumption | Normal mode: 750 mW or less(Current consumption 30 mA or less at 24 V supply voltage) ECO mode: 600 mW or less(Current consumption 25 mA or less at 24 V supply voltage) |
| Output 1(OUT) | NPN open-collector transistor - Maximum sink current: 100 mA - Applied voltage: 30 V DC or less (between output and 0 V) - Residual voltage: 1.5 V or less (at 100 mA sink current) |
| Output 1:Short-circuit protection | Incorporated |
| Output 1:Output operation | Mark mode: Light-ON / Dark-ON (Auto-setting on teaching) Color mode: Consistent-ON / Inconsistent-ON (Setting on teaching) |
