hps+130/DIU/TC/E/G1 Sensor

39790.0 INR/Number

Get a Price/Quote

Product Details:

Sensor Type hps+ ultrasonic sensors
Measurement Range 200 - 5000 mm
IP Rating IP 67
Features Teach-in and numeric configuration via TouchControl LCA-2 with LinkControl
Product Type hps+130/DIU/TC/E/G1
Material brass sleeve, nickel-plated, plastic parts, PBT, TPU
Input com input synchronisation input
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

hps+130/DIU/TC/E/G1 Sensor Price And Quantity

Price 39790.0 INR/Number
Minimum Order Quantity 1 Number

hps+130/DIU/TC/E/G1 Sensor Product Specifications

Features Teach-in and numeric configuration via TouchControl LCA-2 with LinkControl
Warranty 1 year
Product Type hps+130/DIU/TC/E/G1
IP Rating IP 67
Resolution 0.18 mm to 1.5 mm, depending on the analogue window
Output analogue output, pnp: Imax = 200 mA (UB-2V)
Sensor Type hps+ ultrasonic sensors
Measurement Range 200 - 5000 mm
Material brass sleeve, nickel-plated, plastic parts, PBT, TPU
Input com input synchronisation input

hps+130/DIU/TC/E/G1 Sensor Trade Information

Payment Terms Cash in Advance (CID)
Main Domestic Market All India

Product Description

hps+130/DIU/TC/E/G1

1 x pnp + 1 x analogue 4-20 mA / 0-10 V

Measuring Range : 200 - 5000 mm

Design : Process Connection G1

Operating Mode : Proximity Switch/Reflective Mode

Means of Measurement : Echo Propagation Time Measurement

Transducer Frequency : 180 kHz

Blind Zone : 200 mm

Operating Range : 1300 mm

Maximum Range by Normal Pressure : 2000 mm

Resolution : 0.18 mm to 1.5 mm, depending on the analogue window

Type of Connection : 5-pin M12 Initiator Plug

Switching Hysteresis : 20 mm

Switching Frequency : 5 Hz

Response Time : 160 ms

Ultrasonic Transducer : Coated with PTFE film, FFKM O-ring

Controls : 2 push-buttons + LED display (TouchControl)
