Cx-482-P Sensor
2300.0 INR/Number
Product Details:
- Cable Length 2 Meter (m)
- IP Rating IP67 (IEC)
- Sensor Type Compact Photoelectric Sensor
- Application Retroreflective(For transparent object sensing)
- Measurement Range 0.1 to 2 m
- Product Type Compact Photelectric Sensor
- Material Enclosure: PBT (polybutylene terephthalate) Lens: polycarbonate Indicator cover: polycarbonate
- Click to View more
X
Cx-482-P Sensor Price And Quantity
- 2300.0 INR/Number
- 1 Number
- 3000.00 - 3300.00 INR/Number
Cx-482-P Sensor Product Specifications
- Compact Photelectric Sensor
- 80 Grams (g)
- IP67 (IEC)
- 2 Meter (m)
- 0.1 to 2 m
- PNP
- Retroreflective(For transparent object sensing)
- Enclosure: PBT (polybutylene terephthalate) Lens: polycarbonate Indicator cover: polycarbonate
- Compact Photoelectric Sensor
Cx-482-P Sensor Trade Information
- Cash in Advance (CID)
- All India
Product Description
| art Number | CX-482-P |
| Regulatory compliance | EMC Directive, RoHS Directive |
| Sensing range | 0.1 to 2 m0.328 to6.562 ft (Note) The sensing range and the sensing object of the retroreflective type sensor are specifi ed for the RF-230 reflector. The sensing range represents the actual sensing range of the sensor. |
| Sensing object | 50 mm1.969 inor more transparent,translucent or opaque object (Note) The sensing range and the sensing object of the retroreflective type sensor are specifi ed for the RF-230 reflector. The sensing range represents the actual sensing range of the sensor. (Note) Make sure to confirm detection with an actual sensor before use. |
| Hysteresis | - |
| Repeatability(perpendicular to sensing axis) | 0.5 mm0.020 inor less |
| Supply voltage | 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less |
| Current consumption | 10 mA or less |
| Output | PNP open-collector transistor - Maximum source current: 100 mA - Applied voltage: 30 V DC or less (between output and +V) - Residual voltage: 2 V or less (at 100 mA source current), 1 V or less (at 16 mA source current) |
